Yunnei YN4EL089-33 three-stage engine; Aluminum single-row radiator; filler filter with lock, round vernier;
DB55 axis-fixed transmission gearbox, SDLG Reinforced A513 driving axle;
Optimized high-efficient hydraulic system, operated with single handle; load sensing all hydraulic steering;
Double brake pedal, gas-cap oil-clamp disk service brake; mechanical internal expanding shoe drum parking brake
Yunnei YN4EL089-33 three-stage engine, integrated three power curves, multi-level gas-saving mode
Luxury cab in humanized design; stepping instrument; adjustable steering wheel;
Automatic leveling of the bucket with boom lifting limit;
The filters are in centralized layout; the transmission oil filter is arranged externally; the air conditioning evaporator is provided with internal and external circulating filters;
Standard equipped triple valve and the third connector;
Non-slip step ladder adopted;
|Operating weight||Bucket capacity||Rated load||Max.breakout force||Max.dumping height||Dumping distance|
|6800 kg||1.0(1.0-1.4) m³||1800kg||≥58kN||2510mm||920mm|
|Length×Width×Height||Max.tractive force||Total time||Steering angel||Tipping load||Rated power|
|5790×2140×2920 mm||≥56kN||≤9.1s||35°||36KN||65.5 kW|
