ACE Group DJT-8000 Bitumen Melting Machine 8t/h Capacity Large Output Asphalt Heating System for Bulk Production
Product Feature
Product Introduction
The bitumen melting machine is perfectly designed, safe, reliable and easy to operate. The low energy consumption and environmental pollution makes it the first choice of asphalt melting machine.
The job of bitumen melting machine is to extract the solid bitumen by melting method usually from the barrels, bags, and wooden cases. Then the liquid bitumen will work for asphalt mixing equipments and other industrial purpose.
Main Features
1. It utilizes both burning air and oil heating pipe to melt the bitumen, more beneficial for clients.
2. Thermal oil heater inside the main body, small, flexible, and easy to operate.
3. The equipment is given the ability to turn over the barrel, no need to do it yourself.
4. Releases no air pollution, processing part is well protected and sealed.
5. Auto temp-control and bitumen leveling system makes it smart.
6. Low requirement and cost of transportation, because of its excellent structure.
7. Install it anywhere you want, leave your excavator away, it's very simple.
8. Famous burner brand makes it more reliable.
9. Longer service life.
Product Parameter
Model | DJT-8000 |
Capacity (t/h) | 8 |
Bitumen Storage Capacity (m³) | 15 |
Bitumen Pump Flow Rate (m³/h) | 36 |
Number of Barrels | 27 |
Number of Tracks | 3 |
Heating Method | Thermal Oil Heating/Direct Heating |
Bitumen Temperature (℃) | 120 |
Method of Loading Barrels | Cylinder |
Length (mm) | 11600 |
Width (mm) | 3350 |
Height (mm) | 2500 |
Working Voltage (V) | 380 |
Total Electrical Power (kW) | 18 |
Total Weight (kg) | 16000 |
