XCMG XLZ250 Asphalt Mixing Plant
Product Feature
XLZ250 pavement cold recycling machine is a kind of multifunctional road maintenance equipment. It can upgrade the old asphalt pavement and also applicable to the onsite stabilized soil mixing operation for the subgrade and subbase of highways, urban roads, airports, ports, and parking lots.
Features:
• Chongqing Cummins engine, large power and high reliability.
• The load-sensing hydraulic system can set the displacement according to requirements of the executive components; the electro-pneumatic proportional control or the switch control features small pressure loss in the system, convenient operation, stable speed, and reliable performance.
• The double axle drive travel system can provide strong traction force, which can meet the requirements of complicated work conditions.
• The working devices can spray water and emulsified asphalt, and it can make multiple ways of construction.
• The power system adopts automatic power distribution technology, which can allocate the engine power reasonably and effectively, and thus ensures the operating performance.
• The color LCD can display the major parameters of the machine, and it can automatically batch in accordance with the required parameters input according to different construction needs, which achieves the intellectual control of the spraying of water and emulsified asphalt.
Product Parameter
Product Model | XLZ250 | ||
---|---|---|---|
Max. milling & mixing width | mm | 2450 | |
Max. milling & mixing depth | mm | 450 | |
Milling & mixing rotor | No. of blades | 208 | |
Rotor diameter | mm | 1530 | |
Engine | Model | KTA19-C600 | |
Rated power | kW | 448 | |
Rated revs | rpm | 2100 | |
Parameters | Work speed | m/min | 0-2.5 |
Travel speed | km/h | 0-10 | |
Gradeability | % | ≥20%(11,3°) | |
Ground clearance | mm | 400 | |
Work weight | Kg | 29000 | |
Capacity | Fuel tank | L | 800 |
Hydraulic oil tank | L | 350 | |
Water tank | L | 600 | |
Working devices | Installed in the middle | ||
Travel system | Tire | ||
Min. turning radius | m | 7.5 | |
Dimension (L*W*H) | mm | 9963×3231×3539 |
